| Features |
|
|
|
|
| > 25 Languages |
| > Full ASCII character editing |
| > Bluetooth-HID/SPP/Ble+2.4G |
| > Time system |
| PARAMETER |
| > Working current：3.3Vx200mA，( idle:0mA) |
| > Communication distance：Bluetooth≤50m，2.4G≤100m |
| > Storage：1751 barcodes (characters/barcode≤500) |
| > Working time ：3 to 10 days |
| > Charging power：5V-400 mA |
| > Light aimer：617nm LED |
| > illumination：6500K LED |
|
|
|
| > Sensor1280*800 CMOS |
| > Indication：Buzzer & LED |
|
|
|
| > Resolution：1D≥4mil |
| > Decoding speed：300/sec |
|
|
|
| > Printing Contract : > 20% |
|
|
|
| > Trigger Mode：Button，Continuous，Auto-sense |
|
| > Scanning angle：rotation360°，inclination± 60°，declination ± 60° |
| > Anti-interference：0-100000Lux Max |
|
|
| > Decode Ranges(250Lux) |
|
|
|
| |
13mil-EAN13 |
|
40-480mm |
|
| |
4mil-Code39 |
|
20-250mm |
|
| |
20mil-QR |
|
40-450mm |
|
| |
10mil-PDF417 |
|
40-280mm |
|
| > Decode Capability： |
|
|
|
| 1D：UPC，EAN，ISBN, ISSN, Code 128，Code 39，Code32，Code 93, |
| Interleaved 2 of 5，industrial 2 of 5,Matrix 2 of 5, Standard 2 of 5, |
| MSI , Code 11，Codabar, GS1 Data Bar, GS1 composite code。 |
| 2D：QR, Micro QR，Data Matrix，PDF417，MicroPDF417，Aztec Code， |
| Maxi Code，Hanxin。 |
| > LED life：100000 hours |
|
|
|
| > Button life ：1000,000 times |
|
|
|
| > Drop test ：1.8m |
|
|
|
| > Base-Interface：USB, USB-COM, RS232 |
| REGULATORY |
|
|
|
| > CE，FCC，RoHS |
| ENVIRONMENT |
|
|
|
| > Operating Temp. ：-20℃ to 50℃ |
| > Storage Temp. ： -30°C to 60°C |
| > Humidity： 5% – 95% non-condensing |
|
|
| |
|
|
|
|
